SVEN Smart 1500
SVEN Smart 1500
Short product description:
- Sine output voltage both in on-line and off-line mode
- Wide range of input voltage
- High efficiency
- Built-in surge protector
SVEN Pro 400
SVEN Pro 600
SVEN Pro 650 (LCD, USB)
SVEN Pro 800
SVEN Pro 1000 (USB)
SVEN Pro 1500 (LCD, USB)
SVEN UP-L800
SVEN UP-L1000E
SVEN RT-500
SVEN RT-1000
-
FEATURES
-
SPECIFICATIONS
-
DESCRIPTION
-
UNBOXING VIDEO
-
SUPPORT
- Sine output voltage both in on-line and off-line mode
- Wide range of input voltage
- High efficiency
- Built-in surge protector
- LCD display
- Indication of parameters and basic operation modes
- Sound alarm for off-line operation, overload and critical discharge level of storage batteries
- USB and RJ-11/RJ-45 communication ports
- Cold Start function in off-line mode
- Automatic electricity delivery at power supply renewal
- Short circuit and overload protection, pulse and high-frequency disturbance protection
- Modem/telephone circuit protection
| Maximum load, VA/W | 1500/900 |
| Input voltage level, V | 165 – 275 |
| Output voltage level, V | 220 ±10 % (on-line) 220 ± 5 % (via converter) |
| Output voltage waveform | sine wave (on-line and off-line) |
| Frequency, Hz | 50 |
| Communication port | USB, RJ-11/RJ-45 |
| Input terminals | CEE 7/4 |
| Output sockets | 2 × CEE 7/4 |
| Protection | hort circuit and overload modem/telephone circuit |
| Accumulator type | maintenance-free sealed lead-acid batteries (consumables) |
| Accumulators capacity | 12 V 9 А•h (2 pcs) |
| Typical switching time, ms | > 8 |
| Batteries operation time, min | 3-10 min. (depending on the load) |
| Indicators | variables and basic operation modes |
| Processor | RISC-microprocessor based |
| Controlled variable | current input and output voltage, frequency, battery charge level, load condition |
| Environment operation conditions | <5000 m above sea level, 0-50 °C, moisture 0 - 90% without condensation |
| Supported interfaces | intelligent software support of Windows 98/Mе/NT/2000/XP/2003/Vista, Linux, FreeBSD, Novell Netware |
| Certificates | UL. cUL, FCC, [CE,TUV] РосТест |
| Floating time | 4 hours (up to >85 %), 10 hours max (up to >90 %) |
| Dimensions (W × H × D), mm | 145 × 245 × 355 |
| Weight, kg | 13.9 |
| Life time | 5 years |
Other items
Windows/Android/PS3/PS4/XB1/XB360/N-Switch/X-Input/Direct Input compatible gaming steering wheel with shift lever
PS-3/4/XB1S/X/XB360/N-Switch/Windows/Android compatible gaming steering wheel
News
SVEN RX-G995 GAMING MOUSE - ENCHANTING LIGHTING AND TECHNICAL EXCELLENCE
The new gaming mouse SVEN RX-G995 has not only an incredibly attractive and original appearance, but also outstanding technical characteristics that make it an excellent assistant in any games, as well as in work or study.
Details >>
SVEN SRP-155 PORTABLE RADIO — THE BEST OF TWO ERAS
We continue to develop the line of portable radios that remain in demand by numerous fans of timeless classics. The new SVEN SRP-155 combines retro style design with actual modern technologies.
Details >>
SVEN SRP-150 PORTABLE RADIO — RETRO EXTERIOR AND MODERN TECHNOLOGIES INSIDE
Our engineers have repeatedly proven their ability to combine the best elements of classic devices and modern technology. They have applied this skill again in the new SRP-150 portable radio, and they managed to do it at an even more impressive level than before.
Details >>SVEN SMART 1000/1500> line-interactive uninterruptible power supplies featuring sine output voltage are ideal equipment for protecting PCs and peripherals: monitors, modems, etc.
In case of electricity failure, the UPS continues supplying power to the consuming devices using the energy of the integrated storage batteries. The built-in AVR provides proper power supply to the load at over-/undervoltage without entering the off-line mode.
The UPS is designed for computer equipment only. Don't connect household heating appliances, other high-power electric devices and office equipment (room heaters, electric kettles, laser printers, air conditioners, etc.). These appliances increase power consumption considerably, and this can cause the UPS overload and breakdown.
Locate the UPS indoors only, in rooms with controlled air temperature and humidity. During operation, the housing of the device can heat up to 50°C, which is absolutely normal.
