SVEN AVR-1000

Catalog Electrical Equipment Automatic Voltage Regulators SVEN AVR-1000

SVEN AVR-1000

Short product description:

Particular stabilization accuracy of input voltage
Protection of devices-consumers against high/low input volta...
Pause function for safe voltage supply at the power supply r...
Input/output voltage analog indicator on the front panel

All features

Similar products

SVEN VR-L600

SVEN VR-L1000

SVEN VR-L1500

SVEN VR-A1000

SVEN AVR SLIM-500 LCD

SVEN AVR SLIM-1000 LCD

SVEN AVR SLIM-2000 LCD

SVEN VR-F600

SVEN VR-F1000

SVEN VR-F1500

FEATURES
SPECIFICATIONS
DESCRIPTION
UNBOXING VIDEO
SUPPORT

Particular stabilization accuracy of input voltage
Protection of devices-consumers against high/low input voltage, short circuit, high-frequency and high-voltage interferences
Pause function for safe voltage supply at the power supply renewal
Input/output voltage analog indicator on the front panel
Metal case
Optimal solution for unstable power supply networks

Type	relay
Maximum load, W	800 W
Input voltage level, V	100 – 280
Output voltage level, V	220 ± 8 %
Frequency, Hz	50
Output sockets	1
Overload capacity	short-term — up to 150 %, long-term — up to 125%
Indicators	on-line operation, voltage overload, PAUSE mode
Maximum permissible response voltage, V	280 ± 3
Maximal interference current, A	7
Operating temperature, °С	0 ~ 40
Operating humidity, %	10 ~ 90, without condensation
Dimensions (W × H × D), mm	168 × 149 × 250
Weight, kg	3.7
Color	black
Life time	5 years

Other items

SVEN VR-F600

Relay automatic voltage regulator, 200 W, 2 sockets

SVEN GC-3050 Gamepad

Windows/Android/PS3 compatible wireless gamepad

SVEN PS-650

Multifunctional portable karaoke speaker system with backlight

SVEN SB-2200D

Soundbar with wireless subwoofer

SVEN RX-525SW

Wireless Mouse with silent buttons

SVEN KB-G7400

Backlit gaming keyboard

SVEN PS-850

Party speaker system with Bluetooth, karaoke and FM radio

SVEN RX-G730

Backlit gaming mouse

SVEN RX-260W

Wireless mouse

SVEN PS-360

Waterproof portable speaker with karaoke and backlight

SVEN 318

Speaker system with illuminated volume control

SVEN Standard 304 USB+HUB

Wired keyboard with USB port

The automatic voltage regulator of SVEN AVR series is designed to correct on-line power supply in conditions of low/high voltages. The wide range of input voltages from 100 V to 280 V enables the operation of the device in conditions of critical power supply state. The automatic voltage regulator is equipped with protection against short circuit, overload, overheating, overvoltage and undervoltage.

The Pause function (6 or 180 seconds – at option) makes it possible to connect devices-consumers safely to the power supply network at the moment of power supply renewal. The device is equipped with voltmeters, which display the input and output voltages. Due to its strong metal shockproof case the automatic voltage regulator can be also used in technical premises such as a garage, workshop or boiler house.
