SVEN AVR SLIM-500 LCD
Relay automatic voltage regulator, wall-mounted, LCD, 400 W, 1 socket
AN: SV-012809
SVEN AVR SLIM-500 LCD
Relay automatic voltage regulator, wall-mounted, LCD, 400 W, 1 socket
Short product description:
- Microprocessor control
- LED indication of operating modes
- Increased accuracy of output voltage stabilization
- Thermal protection of the transformer
Similar products
SVEN VR-L600
SVEN VR-L1000
SVEN VR-L1500
SVEN VR-A1000
SVEN AVR SLIM-1000 LCD
SVEN AVR SLIM-2000 LCD
SVEN VR-F1000
SVEN VR-F1500
SVEN VR-L600
SVEN VR-L1000
SVEN VR-L1500
SVEN VR-A1000
SVEN AVR SLIM-1000 LCD
SVEN AVR SLIM-2000 LCD
SVEN VR-F1000
SVEN VR-F1500
-
FEATURES
-
SPECIFICATIONS
-
DESCRIPTION
-
UNBOXING VIDEO
-
SUPPORT
- Microprocessor control
- LED indication of operating modes
- Increased accuracy of output voltage stabilization
- Thermal protection of the transformer
- Safe shutdown at high and low mains voltage levels
- Varistor protection against high-voltage impulse noise
- Slim metal body
- Wall mountable
- One EU socket CEE7/4 (EU) with durable fixation of plugs of any type
- Children protection
| AVR type | relay |
| Total power, VА | ≤500 |
| Maximal output power, W | ≤400 |
| Maximum load, W | ≤400 |
| Input voltage, V | ~140 – 260 |
| Output voltage, V | ~220 ± 10 % |
| Input frequency, Hz | 50 |
| Output frequency, Hz | 50 |
| Output sockets | 1 × CEE 7/4 |
| Protection | against high/low voltage in the power supply network, high-frequency and impulse interferences, overload and short circuit; built-in thermal protection |
| Protection operating current, A | 5 |
| Typical switching time, ms | ≤ 10 |
| Indication | output voltage level |
| Indicators | Delaying / protection, Working, Regulating |
| Fuse | bimetallic circuit breaker |
| Input plug | 1 × СЕЕ7/7 |
| Environmental temperature, °С | 0 to +40 |
| Relative humidity, % | 10 ~ 90 (without condensation) |
| Cable length, m | 1.3 |
| Case material | metal |
| Dimensions (W × H × D), mm | 290 × 175 × 60 |
| Weight, kg | 2.48 |
| Color | light grey |
| Life time | 5 years |
Package contents
- Automatic voltage regulator — 1 pc
- User manual — 1 pc
- Warranty card — 1 pc
Other items
News
17.04.2025
SVEN SF-10E-16 EXTENSION SURGE PROTECTOR — SAFE CONNECTION OF UP TO TEN DEVICES
The main thing that is interesting about SVEN SF-10E-16 is, undoubtedly, the safe and convenient connection of up to 10 devices at once, and with a solid total power.
Details >>
07.04.2025
SVEN MC-50 ACOUSTIC HI-FI SYSTEM — PEOPLE'S FLAGSHIP FROM THE LEGENDARY LINE
For decades, multimedia 2.0 acoustics from our company have enabled a wide range of music lovers to experience real Hi-Fi. Our speakers have always been appreciated not only for their good sound, but also for their affordable price.
Details >>
27.03.2025
SVEN PS-1000 AUDIO SYSTEM — EVERYTHING YOU NEED FOR A GRAND PARTY
When the music needs to be loud and the mood needs to be high, the SVEN PS-1000 appears on the party. The new portable acoustics of our company will help you to organize a real dance floor in any place where its owner will appear.
Details >>SVEN TM presents novelties: wall automatic voltage regulators AVR SLIM-500 LCD and AVR SLIM-1000 LCD.
Wall automatic voltage regulators AVR SLIM-500 LCD and AVR SLIM-1000 LCD are designed to supply stabilized voltage to household appliances in conditions of voltage deviations of the single-phase power supply system of lower or higher admissible value. Automatic voltage regulators provide protection of connected electrical appliances and realize their safe connection after power failure removal.
The extended rating of input voltages (140 – 260 V) enables to provide the power supply to appliances even in conditions of critical power supply state. Automatic voltage regulators with different nominal powers up to 400 W (AVR SLIM-500 LCD) and up to 800 W (AVR SLIM-1000 LCD) make it possible to select optimal choice of a model for certain tasks of a user.
The use of microprocessor in the electronic circuit of an automatic voltage regulator enables to realize the following function package – the extended precision of output voltage regulation, display of a current input/output voltage value on LCD display of the front panel, display of AVR status, PAUSE function with the controlled power supply delay (within 6 or 180 sec.) after its resumption, protection against high/low voltage in the power supply network, against high-frequency and impulse interferences, protection of AVR against overload and short circuit. In addition, automatic voltage regulators have thermal protection of the autotransformer.
Compact automatic voltage regulators AVR SLIM-500 LCD and AVR SLIM-1000 LCD have an attractive modern design, as well as wall fasteners. The control panel is located on the right side wall. Constructively AVRs have strong metal housings, due to which they can be installed not only in technical premises, but also in the immediate vicinity with connected devices.
