SVEN OVP-16PD
SVEN OVP-16PD
Short product description:
- Protection of connected devices against high/low voltage in ...
- Protection of connected devices against impulse noises in th...
- Programmable disconnection thresholds and turn-on delay time...
- Nonvolatile memory of programmed settings
SVEN SF-05LU
SVEN Optima 6 sockets
SVEN SF-10E-16
SVEN SF-08E-16
SVEN SF-06E-16
SVEN SF-05PL
SVEN SF-06E
SVEN SF-05E
-
FEATURES
-
SPECIFICATIONS
-
DESCRIPTION
-
UNBOXING VIDEO
-
SUPPORT
- Protection of connected devices against high/low voltage in the power supply network
- Protection of connected devices against impulse noises in the power supply network (varistor)
- Programmable disconnection thresholds and turn-on delay time
- Nonvolatile memory of programmed settings
- Multifunctional LCD display to show voltage level in the power supply net work, delay time and protection status indication
- Protective shutters in the output socket
- Presence of protective, fuse * 15А
| Measured voltage, V | 140 – 280 |
| Operating frequency, Hz | 50 |
| Maximum load current, А | 15 |
| Maximum power, kVА | ≤3.3 |
| Maximum absorbed power, J | ≤125 |
| Maximum absorbed current of pulse distortion, A |
operating mode: 2500 protective mode: 4500 |
| Operation threshold to decrease power supply voltage, V | ~150 - 215 ± 2% |
| Operation threshold to increase power supply voltage, V | ~ 225 - 275 ± 2% |
| Output sockets | 1× СЕЕ 7/4 |
| Protection actuation time, sec | ≤ 0,3 sec |
| Dimensions (W × H × D), mm | 72 × 86 × 77.5 |
| Weight, kg | 0.128 |
| Color | white |
| Life time | 2 years |
